Temperature measuring instrument
(2-channel)

testo 922 – For fast (differential) Temperature measurement

922 Kit complete with
922 Thermometer
2 x Velcro pipe wrap probes
Waterproof emersion probe
Carry case

Features

• Ideally suited for applications in the HVAC field
• 2-channel temperature measuring instrument with optional
  wireless probes

• Display of differential temperature
• TopSafe, the indestructible protective cover, protects from
  dirt and impact

• Continuous display of min./max. values
• Hold-button for freezing measurement values
• Cyclic printing of measurement values, e.g. once per minute

  Description

  Testo 922 is a temperature measuring instrument which is
  especially suited to applications in the HVAC field.
  The measuring instrument records the temperature values of two
  connected thermocouple probes, and shows these
  simultaneously together with the differential temperature in
  the display.
  Measurement data transfer by radio additionally
  allows the measurement value from a further temperature
  probe to be displayed wirelessly.
  With the TopSafe, and the probe plugged in, the measuring
  instrument has protection class IP65.

  The instrument continuously displays the minimum and
  maximum values.
  The measurement values shown in the display (current measurement value, fixed measurement value or the minimum/maximum value) can be printed out on site using the Testo report printer (optional). In addiition to this, the measurement values can be cyclically printed – the intervals can be individually set.

  Technical Data
  Sensor type	Type K (NiCr-Ni)
  Meas. Range	-50 to +1000 °C
  Accuracy ±1 digit	±(0.5 °C +0.3% of mv) (-40 to +900 °C) ±(0.7 °C +0.5% of mv) (remaining range)
  Resolution	0.1 °C (-50 to +199.9 °C)

  General Technical Data
  Oper. temp.	-20 to +50 °C
  Storage temp.	-40 to +70 °C
  Material/Housing	ABS
  Battery type	9V block battery, 6F22
  Battery life	200 h (connected probe, backlight off) 45 h (radio mode, backlight off) 68 h (connected probe, backlight always on) 33 h (radio mode, backlight always on)
  Dimensions	182 x 64 x 40 mm
  Weight	171 g
  Warranty	2 years
